live streaming camera

Type: education teaching camera, e-ecommerce streaming camera, medical trainging camera Model: TCHD-T3 Params: Name HD Live Camera Video System 1080P@60/50/30/25fps,1080i@60/50fps, 720P@60/50fps Sensor 1/2.8'', CMOS, Effective Pixel: 2.07M Scanning Mode Progressive Lens 12x, f3.5mm ~ 42.3mm, F1.8 ~ F2.8 Digital Zoom 16x Minimal Illumination 0.5 Lux @ (F1.8, AGC ON) Shutter 1/30s ~ 1/190s White Balance Auto, 3000K/Indoor, 4000K, 5000K/Outdoor, 6500K_1, 6500K_2, 6500K_3, One Push, Manual Digital Noise Reduction 2D&3D Digital Noise Reduction Video S/N ≥55dB Horizontal Angle of View 72.5° ~ 6.9° Vertical Angle of View 44.8° ~ 3.9° H & V Flip Support Image Freeze Support Number of Preset 255 Network Features Operate System Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android Color System / Compression YUV 4:2:2 / H.264 / MJPEG Video Format "YUY2 (ISOC): max to 1080P@60fps H.264 AVC: max to 1080P@60fps H.264 SVC: max to 1080P@60fps MJPEG: max to 1080P@60fps" Audio on USB Support USB Video Communication Protocol UVC 1.1~1.5 UVC PTZ Support Video compression H.264/H.265MJPEG Video Stream First Stream / Second Stream First Stream resolution 1920x1080, 1280x720, 1024x576, 960x540,640x480, 640x360 Second Stream resolution 1280x720, 1024x576, 720x576 (50Hz support),720x480(60Hz support), 720x408, 640x360, 480x270, 320x240, 320x180 Video Bit Rate 32Kbps ~ 20480Kbps Bit Rate Control CBR, VBR Frame Rate 50Hz: 1fps ~ 25fps, 60Hz: 1fps ~ 30fps Audio Compression AAC Audio Bit Rate 96Kbps, 128Kbps, 256Kbps Support protocols TCP/IP, HTTP, RTSP,RTMP, ONVIF, DHCP, Multicast, etc. Interface/Button USB Interface 1xUSB3.0: Type C, 1 x USB 2.0: Type A, HD Output 1x HDMI 1.4b Audio Interface 1-ch: 3.5mm Audio Interface, Line In Network Interface 1 x RJ45: 10M/100M, Adaptive Ethernet Port, support PoE Power Jack JEITA type (DC IN 12V) "H & V Screen Button " Vertical Screen/Horizontal Screen Material: plastic glass Applicable Industry: broadcasting, medical , e-ecommerce streaming, education teaching, event streaming camera camera camera
